Radar Matic RF-880L

Radar Matic RF-880L; Panasonic, (ID = 2238275) Radio Radar Matic RF-880L; Panasonic, (ID = 1058915) Radio
Radar Matic RF-880L; Panasonic, (ID = 1058907) Radio Radar Matic RF-880L; Panasonic, (ID = 86258) Radio
Radar Matic RF-880L; Panasonic, (ID = 86257) Radio Radar Matic RF-880L; Panasonic, (ID = 576300) Radio
Radar Matic RF-880L; Panasonic, (ID = 1058908) Radio Radar Matic RF-880L; Panasonic, (ID = 1058909) Radio
Radar Matic RF-880L; Panasonic, (ID = 1058910) Radio Radar Matic RF-880L; Panasonic, (ID = 1058911) Radio
Use red slider bar for more.
Radar Matic RF-880L; Panasonic, (ID = 2238275) Radio
Panasonic,: Radar Matic RF-880L [Radio] ID = 2238275 1400x1406
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radar Matic RF-880L, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Other, details in remarks or not known. / D: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Radar Matic RF-880L - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 266 x 184 x 86 mm / 10.5 x 7.2 x 3.4 inch
Notes

National Panasonic Radar Matic RF-880L;
FM up to 108 MHz, LW 150 - 300 KHz, Motor driven tuning, tone control, loc./DX sensitivity switch, dial light, earphones/ext. speaker jack, AFC, multi-connector socket for suitable car bracket type RD-880LC as an option, compare different coverage with RF-880 model.

Power supply from 6 or 12 V car battery is possible with an adapter.

Net weight (2.2 lb = 1 kg) 2.7 kg / 5 lb 15.2 oz (5.947 lb)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Here you find 2667 models, 2427 with images and 508 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Panasonic,: Radar Matic RF-880L
Threads: 2 | Posts: 2
Hits: 1975     Replies: 0
panasonic: RF-880L; Radar Matic
Wolfgang Scheida
30.May.11
  1

Im Modelltext wird bereits auf das Vorhandensein mehrere Versionen hingewiesen.

MfG


Hits: 1490     Replies: 0
panasonic: RF-880L; Radar Matic: Version für Region 1
Dietmar Rudolph
30.May.11
  1

Todd Stackhouse informierte mich, daß es von der Type "Radar Matic RF-880" zwei Versionen gibt:

  • Radar Matic RF-880 (für Region 2: "die Americas") mit den Wellenbereichen
    MW, MB („Seeband“) 1,6...4 MHz, u. UKW.
  • Radar Matic RF-880L (für Region 1: "Europa") mit den Wellenbereichen
    MW, LW u. UKW ["L" für "long wave"?]

Z. Zeit (30.05.2011)  sind infolge eines Fehlers beim Upload die Pläne für den RF-880L beim RF-880 hochgeladen.

Ich möchte den Schaltplan Admin bitten, die Pläne zum RF-880L zu verschieben.

MfG DR


Panasonic,: Radar Matic RF-880L
End of forum contributions about this model
