Radar Matic RF-980L

Radar Matic RF-980L; Panasonic, (ID = 1000092) Radio Radar Matic RF-980L; Panasonic, (ID = 999995) Radio
Radar Matic RF-980L; Panasonic, (ID = 999996) Radio Radar Matic RF-980L; Panasonic, (ID = 999997) Radio
Radar Matic RF-980L; Panasonic, (ID = 999998) Radio Radar Matic RF-980L; Panasonic, (ID = 999999) Radio
Radar Matic RF-980L; Panasonic, (ID = 1000090) Radio Radar Matic RF-980L; Panasonic, (ID = 1000091) Radio
Use red slider bar for more.
Radar Matic RF-980L; Panasonic, (ID = 1000092) Radio
Panasonic,: Radar Matic RF-980L [Radio] ID = 1000092 933x804
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radar Matic RF-980L, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 18: 2SC429 2SC185 2SC183 2SC645 2SC469 2SC469 2SC469 2SC469 2SC183 2SC183 2SB324 2SB324 2SC183 2SC183 2SB173 2SB175 2SB324 2SB324
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage and/or dry batteries / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out
from Radiomuseum.org Model: Radar Matic RF-980L - Panasonic, Matsushita,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 185 x 83 mm / 10.4 x 7.3 x 3.3 inch
Notes Das Radio hat einen automatischen Sendersuchlauf. Der Skalenzeiger wird mechanisch bewegt. Rechts befinden sich zwei Buchsen für Kopfhörer und drei Remote-Buchsen. Links befinden sich zwei Buchsen: MPX-out und Stereo-in. Ausserdem ein Schalter für AFC on-off.
Net weight (2.2 lb = 1 kg) 2.7 kg / 5 lb 15.2 oz (5.947 lb)
Source of data - - Data from my own collection

Model page created by Stephan Manthei. See "Data change" for further contributors.
