- Country
- Japan
- Manufacturer / Brand
- Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Year
- 1973
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 148934
Original National Prospekt 1973
Original National Prospekt 1973
- Number of Transistors
- 10
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Radio with other functions
- Power type and voltage
- Dry Batteries / 5 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RC-7580 - Panasonic, Matsushita,
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 235 x 100 x 105 mm / 9.3 x 3.9 x 4.1 inch
- Notes
-
AM/FM-Uhrenradio, netzunabhängig, Stimmgabeltechnik. 24 Stunden vorprogrammierbar. Wecken durch Radio oder Alarm. Available with clock movements 12 AM/PM hour or 24 hour system depends on market.Gross weight incl full packing 2.1 kg.g. Gehäuse in Weiss oder Weiss-marmoriert. 10 Transistoren, 1 FET.
LED clock indicator, push button for clock light, 0 - 60 min sleep function, AFC, Tone Hi / Lo, external antenna and earphone jack at back of unit
- Net weight (2.2 lb = 1 kg)
- 1.8 kg / 3 lb 15.4 oz (3.965 lb)
- Price in first year of sale
- 349.00 DM
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
