• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 183597

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 26

• Semiconductors
• 2SB473 2SB473 2SB473 2SB473 2SC469 2SK19 2SC920 2SC920 2SC469 2SC469 2SC469 2SC183 2SC183 2SA101 2SC183 2SB178 2SA564 2SA564 2SB173 2SB173 2SB173 2SB173 2SB178 2SB176 2SB176 2SC183

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: RE-7670B - Panasonic, Matsushita,

• Shape
• Rack

• Dimensions (WHD)
• 420 x 245 x 95 mm / 16.5 x 9.6 x 3.7 inch

• Notes
• FM Multiplex Stereo. Diodos: 1S351; 3-1S1211; 10-1N34A; KC2dP(bridge rectifier)

• Net weight (2.2 lb = 1 kg)
• 4.8 kg / 10 lb 9.2 oz (10.573 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Gil Silva. See "Data change" for further contributors.
