RE-787

• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1967

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 100162

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 26

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-120 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 8 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: RE-787 - Panasonic, Matsushita,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 440 x 330 x 150 mm / 17.3 x 13 x 5.9 inch

• Notes

• Stereo-Tischgerät mit Motorsuchlauf. Separate Lautsprecherbox für den den rechten Kanal. Separate LS-Box: 308mm x330mm x130mm.

  Power Consumption 8 Watts.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)
