• Year
  • 1974 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 125854

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 19
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, more than 2 SW bands plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 110-125; 220-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 6 Band Receiver RF-1180B - Panasonic, Matsushita,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 302 x 211 x 99 mm / 11.9 x 8.3 x 3.9 inch
  • Notes
  • Panasonic RF-1180B;
    FM: 76-108 MHz;
    SW1: 1.6-3.6 MHz,
    SW2: 3.6-7.5 MHz,
    SW3: 7.5-15 MHz,
    SW4: 15-30 MHz,
    120 min timer, MW SW RF gain control,
    tune/batt. indicator, rotary ferrite rod antenna. Bestückung: 1 IC; 19 Transistoren; 18 Dioden
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
