FM-LW-MW 3 Band Receiver RF-1650L GX-50

FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375992) Radio FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375994) Radio
FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375995) Radio FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375996) Radio
FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375997) Radio FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375998) Radio
FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375999) Radio FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1376334) Radio
FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1376336) Radio FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1376337) Radio
Use red slider bar for more.
FM-LW-MW 3 Band Receiver RF-1650L GX-50; Panasonic, (ID = 1375992) Radio
Panasonic,: FM-LW-MW 3 Band Receiver RF-1650L GX-50 [Radio] ID = 1375992 933x562
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM-LW-MW 3 Band Receiver RF-1650L GX-50, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1985 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 4:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 240 / 4 × 1,5 C Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: FM-LW-MW 3 Band Receiver RF-1650L GX-50 - Panasonic, Matsushita,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 266 x 143 x 81 mm / 10.5 x 5.6 x 3.2 inch
Notes 3 IC´s.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
