RF-513

RF-513; Panasonic, (ID = 1426117) Radio RF-513; Panasonic, (ID = 262743) Radio
Use red slider bar for more.
RF-513; Panasonic, (ID = 1426117) Radio
Panasonic,: RF-513 [Radio] ID = 1426117 779x1400
Select picture or schematic to display from thumbnails on the right and click for download.
For model RF-513, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
By courtesy of EBAY Seller: pittsburgh_clcokshop

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RF-513 - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Mentioned in -- Collector info (Sammler)

Model page created by Peter Hoddow. See "Data change" for further contributors.



All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Here you find 2667 models, 2427 with images and 508 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
