For model RF-542, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1990 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 1: 2SC829 TA8100 TA7358
Main principle ZF/IF 455 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / AA: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: RF-542 - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 212 x 161 x 56 mm / 8.3 x 6.3 x 2.2 inch
Notes

2 Integrierte Schaltungen. Das Gerät wurde in schwarz und in weiß gebaut.

Made in Singapore.

2 integrated circuits. The device was built in black and white.

Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
