Touch n Tune RF-545 L

Touch n Tune RF-545 L; Panasonic, (ID = 86227) Radio

Touch n Tune RF-545 L; Panasonic, (ID = 86228) Radio
Touch n Tune RF-545 L; Panasonic, (ID = 86224) Radio Touch n Tune RF-545 L; Panasonic, (ID = 86225) Radio
Touch n Tune RF-545 L; Panasonic, (ID = 86226) Radio Touch n Tune RF-545 L; Panasonic, (ID = 1427484) Radio
Touch n Tune RF-545 L; Panasonic, (ID = 1427485) Radio Touch n Tune RF-545 L; Panasonic, (ID = 1427486) Radio
Touch n Tune RF-545 L; Panasonic, (ID = 1526617) Radio Touch n Tune RF-545 L; Panasonic, (ID = 1526618) Radio
Touch n Tune RF-545 L; Panasonic, (ID = 1526620) Radio Touch n Tune RF-545 L; Panasonic, (ID = 1526621) Radio
Use red slider bar for more.
Touch n Tune RF-545 L; Panasonic, (ID = 86224) Radio
Panasonic,: Touch n Tune RF-545 L [Radio] ID = 86224 933x697
Select picture or schematic to display from thumbnails on the right and click for download.
For model Touch n Tune RF-545 L, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1988 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7:
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220; 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Touch n Tune RF-545 L - Panasonic, Matsushita,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 252 x 145 x 83 mm / 9.9 x 5.7 x 3.3 inch
Notes 3 Integrierte Schaltungen. 3 FM Stationstasten.

Panasonic Touch 'n' Tune RF-545L portable radio;
Switch manual tuning / 3 x FM preset, earphone and external speaker socket.
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Source of data -- Original-techn. papers.

Model page created by Johann Schönauer. See "Data change" for further contributors.



All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
