RQ-209DS

RQ-209DS; Panasonic, (ID = 1046656) R-Player RQ-209DS; Panasonic, (ID = 1045573) R-Player
RQ-209DS; Panasonic, (ID = 1045574) R-Player RQ-209DS; Panasonic, (ID = 1045575) R-Player
RQ-209DS; Panasonic, (ID = 1045576) R-Player RQ-209DS; Panasonic, (ID = 1045577) R-Player
RQ-209DS; Panasonic, (ID = 1045578) R-Player RQ-209DS; Panasonic, (ID = 1079163) R-Player
RQ-209DS; Panasonic, (ID = 1079164) R-Player RQ-209DS; Panasonic, (ID = 1079165) R-Player
Use red slider bar for more.
RQ-209DS; Panasonic, (ID = 1046656) R-Player
Panasonic,: RQ-209DS [R-Player] ID = 1046656 850x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model RQ-209DS, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1970 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 1:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 90-110; 110-125; 200-220; 220-250/ 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: RQ-209DS - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 138 x 70 x 259 mm / 5.4 x 2.8 x 10.2 inch
Notes 1 Transistor, 1 IC, Does not have built-in microphone (mic was supplied with unit)
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Source of data - - Manufacturers Literature

Model page created by Walter Steinwender. See "Data change" for further contributors.
