Stereo Radio Cassette Recorder RX-FS400

Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164317) Radio Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164318) Radio
Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164319) Radio Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164320) Radio
Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164321) Radio Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164322) Radio
Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164323) Radio Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2243017) Radio
Use red slider bar for more.
Stereo Radio Cassette Recorder RX-FS400; Panasonic, (ID = 2164317) Radio
Panasonic,: Stereo Radio Cassette Recorder RX-FS400 [Radio] ID = 2164317 1400x487
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Radio Cassette Recorder RX-FS400, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1995 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / D: 6 x 1,5 Volt
Loudspeaker 2 Loudspeakers / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Stereo Radio Cassette Recorder RX-FS400 - Panasonic, Matsushita,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 450 x 145 x 140 mm / 17.7 x 5.7 x 5.5 inch
Notes

Die 6 Schrauben an der Rückseite sind jeweils mit einem schwarzen Punkt zu finden.

Made in Singapore.

Net weight (2.2 lb = 1 kg) 2.285 kg / 5 lb 0.5 oz (5.033 lb)

Model page created by Ottmar Lauth. See "Data change" for further contributors.
