Panasonic,: TV Color TX-25MD1E [Television] ID = 2580461 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model TV Color TX-25MD1E, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 2000 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 30 W (undistorted)
from Radiomuseum.org Model: TV Color TX-25MD1E - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 531 x 601 x 440 mm / 20.9 x 23.7 x 17.3 inch
Notes
  • TV color
  • Output Audio monitor RCA
  • Output 2 AV
  • Imput AV3 RCA
  • TXT



Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.



All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Here you find 2622 models, 2379 with images and 507 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
