Panoramic Radio Adaptor RCX

Panoramic Radio Adaptor RCX; Panoramic Radio Corp (ID = 1104864) Misc
Panoramic Radio Adaptor RCX; Panoramic Radio Corp (ID = 1104870) Misc Panoramic Radio Adaptor RCX; Panoramic Radio Corp (ID = 613419) Misc
Use red slider bar for more.
Panoramic Radio Adaptor RCX; Panoramic Radio Corp (ID = 1104870) Misc
Panoramic Radio Corp: Panoramic Radio Adaptor RCX [Misc] ID = 1104870 651x397
Select picture or schematic to display from thumbnails on the right and click for download.
For model Panoramic Radio Adaptor RCX, Panoramic Radio Corp.; New York (NY):
Picture from US Navy manual for RCX is in public domain.

Country:  United States of America (USA)
Manufacturer / Brand:  Panoramic Radio Corp.; New York (NY)
Year: 1944 Category: Miscellaneous (Other, Various) - see notes
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 115; 230 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Panoramic Radio Adaptor RCX - Panoramic Radio Corp.; New
Material Metal case
Shape Boatanchor (heavy military or commercial set).
Dimensions (WHD) 18 x 7 x 18 inch / 457 x 178 x 457 mm
Notes

Panoramic Radio Adaptor RCX;
Frequency band analyzer/ radio spectroscope with CRT, input IF 450 - 475 kHz, made for Navy Department Bureau of Ships.

Model page created by a member from A. See "Data change" for further contributors.
