- Country
- France
- Manufacturer / Brand
- Pathé-Marconi, Les IME (I.M.E.), La Voix de son Maître; Paris
- Year
- 1965 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 132223
-
- alternative name: La Voix de son Maître
Manufacturer documentation
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); 3 AF stage(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 80T4 - Pathé-Marconi, Les IME I.M.E.,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 326 x 188 x 103 mm / 12.8 x 7.4 x 4.1 inch
- Notes
- 80T4 (Pathé Marconi)est un récepteur à 10 transistors et 6 diodes.
- Net weight (2.2 lb = 1 kg)
- 3.5 kg / 7 lb 11.3 oz (7.709 lb)
- Author
- Model page created by Jacky Parmentier. See "Data change" for further contributors.
