- Country
- France
- Manufacturer / Brand
- Perlor Radio; Paris
- Year
- 1954 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 257649
Photo Perlor Radio
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit. / 6,3 & 290 & 760 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: OS7 - Perlor Radio; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 270 x 200 x 180 mm / 10.6 x 7.9 x 7.1 inch
- Notes
-
Cet oscilloscope a besoin pour fonctionner d'une alimentation externe qui lui délivre du 6.3 VAC, 290 VDC et du 760 VDC. Pour ce faire, Perlor Radio a prévue une alimentation AL5.
- Amplificateur Horizontal : 2 Hz à 1 MHz, à -3 dB.
- Amplificateur Vertical : 2 Hz à 3 MHz, à -3 dB.
- Sensibilité : de 5 mV à 150 V.
- Impédance d'entrée : 3.3 MΩ / 30 pF.
- Base de temps : 5 gammes 10 Hz, 80 Hz, 400 Hz, 3 KHz et 30 KHz.
- Net weight (2.2 lb = 1 kg)
- 4.5 kg / 9 lb 14.6 oz (9.912 lb)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Jean Marchal. See "Data change" for further contributors.
