H52; Peto-Scott Co., The: (ID = 363235) Radio
Peto-Scott Co., The:: H52 [Radio] ID = 363235 595x595
Select picture or schematic to display from thumbnails on the right and click for download.
For model H52, Peto-Scott Co., The: Electrical Instruments Ltd.; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Peto-Scott Co., The: Electrical Instruments Ltd.; London
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: X61M KTW61M DH63 KT61 U50
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: H52 - Peto-Scott Co., The:
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 19 x 16.5 x 10 inch / 483 x 419 x 254 mm
Notes same cabinet for H51.
Price in first year of sale 19.95 £
Source of data Radio! Radio!

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
