• Year
  • 1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 201929

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 4 inch = 10.2 cm
  • from Radiomuseum.org
  • Model: A1 - Philco Radio & Television Corp
  • Shape
  • Tablemodel with Push Buttons.
  • Notes
  • Midget table radio with six push buttons, five for pre-set radio stations (three on MW, two on LW) and the sixth for selecting manual tuning. A similar chassis is fitted in the Philco A1 radiogram.
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
