A-T2262HM Ch= 81, H-1 Code 123

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694175) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694176) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694177) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694178) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694179) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694180) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694181) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694182) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694183) Television

A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694184) Television
Use red slider bar for more.
A-T2262HM Ch= 81, H-1; Philco, Philadelphia (ID = 1694175) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1953 Category: Television Receiver (TV) or Monitor
Valves / Tubes 18: 6BZ7 12AZ7 6CB6 6CB6 6CB6 12BY7 6AU6 6T8 6K6GT 6U8 6BE6 12BH7 6AL5 12AU7 6BQ6GT 6AX4GT 1B3GT 21EP4A
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 117 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: A-T2262HM Ch= 81, H-1 [Code 123] - Philco, Philadelphia Stg. Batt
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes

The Philco A-T2262HM is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with RF chassis 81, Deflection chassis H-1 and picture tube 21EP4A.

Mentioned in Photofact Folder, Howard W. SAMS (201/ April 1953)
Literature/Schematics (1) - - Manufacturers Literature (Philco Television Yearbook - 1953 Pages 87-111)

Model page created by John Kusching. See "Data change" for further contributors.
