A-UT1816L Ch= 81, H-1 Code 123

Philco, Philadelphia Stg. Batt. Co.; USA

  • Year
  • 1953
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 255318

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 117 Volt
  • Loudspeaker
  • Permanent or electro-dynamic (moving coil), system not known yet.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: A-UT1816L Ch= 81, H-1 [Code 123] - Philco, Philadelphia Stg. Batt
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 26 x 40 x 25 inch / 660 x 1016 x 635 mm
  • Notes
  • The Philco A-UT1816L is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with RF chassis 81, Deflection chassis H-1 and picture tube 17YP4.






  • Literature/Schematics (1)
  • - - Manufacturers Literature (Philco Television Yearbook - 1953 Pages 163-192)
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
