• Year
  • 1956
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 134637

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Power out
  • 1 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: D-1333 "Ginger" - Philco, Philadelphia Stg. Batt
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Notes
  • The Philco Model D-1333 is an AC operated 1 Tube and 1 Selenium Rectifier portable Phono Amplifier and a 3 Speed Record Player. Cabinet is "Ginger" color plastic over wood, with carrying handle. This model has Qty(1) 4" PM speaker. Record Player has speeds of 33-1/3, 45 and 78 RPM and uses a 90V motor.
  • Literature/Schematics (1)
  • Philco Home Radio Yearbook 1956
  • Literature/Schematics (2)
  • - - Manufacturers Literature
  • Author
  • Model page created by Thomas Albrecht. See "Data change" for further contributors.
