- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 134664
Picture from Philco datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- AC/DC-set / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 1 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: F-976 - Philco, Philadelphia Stg. Batt
- Shape
- Tablemodel, with any shape - general.
- Notes
- The Philco Model F-976 is an AC/DC operated 7 Tube and 1 selenium rectifier AM/FM Receiver. Cabinet is Blonde, Mahogany or Fruitwood. AM Band Tuning Range: 540 to 1620KHz. FM Band Tuning Range: 88 to 108MHz. Internal loop antenna for AM, uses line cord for FM with provision for connecting external antenna.
- Literature/Schematics (1)
- Philco Home Radio Yearbook 1958
- Literature/Schematics (2)
- - - Manufacturers Literature
- Author
- Model page created by Thomas Albrecht. See "Data change" for further contributors.
