G-1906S Code 123

Philco, Philadelphia Stg. Batt. Co.; USA

Data
Forum
Pictures
Collections

  • Year
  • 1958/1959
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 213375

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 105-120 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 30 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: G-1906S Code 123 - Philco, Philadelphia Stg. Batt
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 37.375 x 32 x 17.125 inch / 949 x 813 x 435 mm
  • Notes

  • The Philco Model G-1906S (Code 123) is an AC operated 6 Tube Phono Amplifier and a 4 Speed Record Changer. Uses Record Changer M-41 with speeds of 16-2/3, 33-1/3, 45 and 78 RPM. Also has a stereo cartridge, with output jack for stereo conversion. This model has Qty(1) 15" PM woofer and Qty(2) type "P" electrostatic speakers. Cabinet is Blonde, Fruitwood or Mahogany. Philco model G-1906S (Code 121) is similar except uses a 12AX7 pre-amp tube in place of the 7025 tube used in this model.

  • Source of data
  • - - Manufacturers Literature
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Photofact Folder, Howard W. SAMS (Date 11-59, Set 464, Folder 17))
  • Literature/Schematics (3)
  • Philco Folder AD-1793 for 1959.
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
