• Year
  • 1962 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 90033

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • AC/DC-set / 117 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: L-928 - Philco, Philadelphia Stg. Batt
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • The Philco L-928 is an AC operated 6 tube AM/FM clock radio.  Has built-in loop antenna for AM and uses line cord as FM antenna with provisions for connecting an external FM antenna.

    Sams photofact, set 647, folder 10, date 8-63, features the Philco models L-799, L-926, L-927, L-928 and L-929 as the same schematic. Only model L-799 with electric clock.

  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 23, 1963
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Philco Home Radio Service Data PR-3743 Dated 1962)
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
