- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1957
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 213770
Picture from Philco datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 90 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: M-40A - Philco, Philadelphia Stg. Batt
- Shape
- Chassis only or for «building in»
- Notes
- The Philco model M-40A is a four speed automatic record changer. This record changer is designed to play 7", 10" and 12" records at 78, 33-1/3, 45 and 16 RPM. This record changer is similar to model M-40 except for the drive motor and cartridge. The motor is designed for 90V, 60 cycle AC only. The 90V motor is connected in series with the filament of a 25V tube (usually a 25L6).
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
