Three Band Super A637
Philco Radio & Television Corp. of Great Britain Ltd.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Philco Radio & Television Corp. of Great Britain Ltd.; London
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 352500
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 451 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 50-100Hz, 200-250; 251-260 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Three Band Super A637 - Philco Radio & Television Corp
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Wavebands:-
- LW 937.5 - 2000 metres
- MW 176.4 - 545.4 metres
- SW 16.6 - 52.6 metres
Sockets for gramophone and external loudspeaker
- Price in first year of sale
- 13.65 GBP
- Literature/Schematics (1)
- Broadcaster Service Man's Manual January 1938
- Author
- Model page created by Clive Forder. See "Data change" for further contributors.
