UF4621S Ch= 8L43U

• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1958

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 196256

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• 6X8 6BC8 6AF4A 6AM8 6DE6 6DE6 12AU7A 6T8 6CU5 6BY8 6AW8A 6CS7 5U4GB 6DQ6A 1B3GT 6AX4GT 21CMP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 105-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: UF4621S Ch= 8L43U - Philco, Philadelphia Stg. Batt

• Notes
• The Philco UF4621S is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 8L43U, tuner T-69A and picture tube 21CMP4.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 5-58, Set 399, Folder 2)

• Literature/Schematics (2)
• - - Manufacturers Literature

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
