• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1973

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 312357

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: 10 inch Round High Fidelity Woofer Loudspeaker AD10100 /W4 /W8 - Philips; Eindhoven tubes

• Dimensions (WHD)
• 261.1 x 261.1 x 130.8 mm / 10.3 x 10.3 x 5.1 inch

• Notes

• Philips 10 inch Round High Fidelity Loudspeaker type AD10100 /W

  Available versions:

  • /W4:         Z= 4 Ω @ 20 Hz
  • /W8:         Z= 8 Ω @ 20 Hz

• Net weight (2.2 lb = 1 kg)
• 3.270 kg / 7 lb 3.2 oz (7.203 lb)

• Mentioned in
• -- Original-techn. papers. (Miniwatt Copresa "Altavoces" 1973)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
