- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1967
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 125926
Das Gerät hat die Nr. 413253
Hier das konische Zwischenrad (1)
Konisches Zwischenrad (2)
Collection Privée - Patrice Schoser
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 3×1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.1 cm = 2 inch
- Power out
- 0.15 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 11RL080 /00 - Philips; Eindhoven tubes
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 115 x 74 x 36 mm / 4.5 x 2.9 x 1.4 inch
- Notes
-
Leiterplatte mit Miniaturfiltern. Ferritantenne 6,3 cm - flach 13×4 mm, Lautsprecher: AD2218.
Aufwändige Zahnradkonstruktion für die Senderabstimmung - der Antrieb hat durch die konische Form und federnde Lagerung des Zwischenrades kein Spiel.
- Net weight (2.2 lb = 1 kg)
- 0.2 kg / 0 lb 7 oz (0.441 lb)
- Author
- Model page created by Alfred Przybilla. See "Data change" for further contributors.
