Ministor IV (4) 11RL274T /00S /00X /00Z

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481962) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481963) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481964) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481965) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481966) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481968) Radio

Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481973) Radio
Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 2358903) Radio Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 2358904) Radio
Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 1481734) Radio Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 2124783) Radio
Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 2005087) Radio
Use red slider bar for more.
Ministor IV 11RL274T /00S /00X /00Z; Philips France; (ID = 2358903) Radio
Philips France;: Ministor IV 11RL274T /00S /00X /00Z [Radio] ID = 2358903 1400x680
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ministor IV (4) 11RL274T /00S /00X /00Z, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF127 AF127 AC127 AC126 AC127 AC132 OA79 BA114
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 6 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: Ministor IV 11RL274T /00S /00X /00Z - Philips France; Paris
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 192 x 107 x 45 mm / 7.6 x 4.2 x 1.8 inch
Notes

2 gammes d'ondes : PO de 187 à 572 m, GO de 1150 à 1950 m. Cadre ferroxcube de 17.5 cm. HP type AD3317HZ, Z = 25 ohms. Prise pour écouteur avec coupure du HP incorporé.

Coffret cicolac, sacoche sur demande. 3 exécutions :

  • /00S gris
  • /00X bleu
  • /00Z carmin

Le no. spécial du Haut Parleur 1966 mentionne une alimentation par 4 piles 1.5 volt, qui est très probablement erronnée. Une publicité d'année 1966 indique 8 transistors, qui est erronnée également.

Voir aussi modèle 11RL274T /01 d'année 1969 avec des différences mineures.

Mentioned in -- Original-techn. papers.
Literature/Schematics (1) -- Original prospect or advert
Literature/Schematics (2) Le Haut-Parleur (No. spécial, 30.10.1966)

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
