122ABC -12

122ABC -12; Philips; Eindhoven (ID = 2150593) Radio 122ABC -12; Philips; Eindhoven (ID = 2150594) Radio
122ABC -12; Philips; Eindhoven (ID = 2150596) Radio 122ABC -12; Philips; Eindhoven (ID = 2150598) Radio
122ABC -12; Philips; Eindhoven (ID = 2149464) Radio 122ABC -12; Philips; Eindhoven (ID = 2150636) Radio
122ABC -12; Philips; Eindhoven (ID = 2150638) Radio 122ABC -12; Philips; Eindhoven (ID = 2150639) Radio
122ABC -12; Philips; Eindhoven (ID = 2150640) Radio 122ABC -12; Philips; Eindhoven (ID = 2150641) Radio
Use red slider bar for more.
122ABC -12; Philips; Eindhoven (ID = 2150593) Radio
Philips; Eindhoven: 122ABC -12 [Radio] ID = 2150593 1400x1524
Select picture or schematic to display from thumbnails on the right and click for download.
For model 122ABC -12, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK21 DF21 DAC21 DL21
Main principle Superheterodyne (common)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / AC/DC 110-230 / 4,5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 122ABC -12 - Philips; Eindhoven tubes
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 290 x 180 mm / 10.2 x 11.4 x 7.1 inch
Notes

Heizung mit drei Flachbatterien 4,5 V parallel geschaltet.

Das Philips Modell 122ABC -12 hat eine Skaleneinfassung aus lackiertem Holz.
Siehe auch Modell 122ABC -06 -08 mit Einfassung aus Bakelit.

Abweichend ist weiterhin die Rückwand mit Lage der Befestigungsschrauben und Halterung für den Netzstecker bei Batteriebetrieb.

Net weight (2.2 lb = 1 kg) 3.570 kg / 7 lb 13.8 oz (7.863 lb)

Model page created by Bernhard Nagel. See "Data change" for further contributors.
