• Year
  • 1983 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 277922

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 17
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Line plus power jack, mostly with battery or storage battery / 220 / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 12TX2460 /20X /22X Ch= TX-2 - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 392 x 297 x 299 mm / 15.4 x 11.7 x 11.8 inch
  • Net weight (2.2 lb = 1 kg)
  • 6.5 kg / 14 lb 5.1 oz (14.317 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
