212 Electronic 22GA212 /05Z

212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 244138) R-Player

212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 244139) R-Player

212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 244140) R-Player

212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 244141) R-Player

212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 244137) R-Player
212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 135609) R-Player 212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 135611) R-Player
212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 135610) R-Player 212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 135614) R-Player
212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 513478) R-Player 212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 1435649) R-Player
Use red slider bar for more.
212 Electronic 22GA212 /05Z; Philips; Eindhoven (ID = 135609) R-Player
Philips; Eindhoven: 212 Electronic 22GA212 /05Z [R-Player] ID = 135609 640x589
Select picture or schematic to display from thumbnails on the right and click for download.
For model 212 Electronic 22GA212 /05Z, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1972–1976 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 17:
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 212 Electronic 22GA212 /05Z - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 390 x 150 x 335 mm / 15.4 x 5.9 x 13.2 inch
Notes Frequenzgesteuerter Motor mit Riementrieb, Blechteller, gefedertes Subchassis, optische Endabschaltung ohne Rückführung. Sensortasten für Start, 33/45 UpM und Stop, Antiskating
Net weight (2.2 lb = 1 kg) 5.9 kg / 12 lb 15.9 oz (12.996 lb)
Price in first year of sale 450.00 Dfl
Source of data Handbuch VDRG 1972/1973
Mentioned in Handbuch VDRG 1973/1974 (bis 1975/76)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Urs Gloor. See "Data change" for further contributors.
