Fiesta 223

Fiesta 223; Philips Australia (ID = 1780400) Radio

Fiesta 223; Philips Australia (ID = 1780401) Radio

Fiesta 223; Philips Australia (ID = 1780402) Radio

Fiesta 223; Philips Australia (ID = 1780403) Radio

Fiesta 223; Philips Australia (ID = 1780404) Radio

Fiesta 223; Philips Australia (ID = 1780405) Radio
Fiesta 223; Philips Australia (ID = 1779775) Radio
Use red slider bar for more.
Fiesta 223; Philips Australia (ID = 1779775) Radio
Philips Australia: Fiesta 223 [Radio] ID = 1779775 500x343
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fiesta 223, Philips Australia:
Philips model 223 from service sheet title page.

Country:  Australia
Manufacturer / Brand:  Philips Australia
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6AN7 6N8 6BM8 6BM8 6V4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker 2 Loudspeakers / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: Fiesta 223 - Philips Australia
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 44 x 29 x 16 inch / 1118 x 737 x 406 mm
Notes

This stereo radiogram uses a Philips NG1020 record changer with an AG3301 pick-up head.  A separate speaker box, model 223, (dimensions: 12" x 12¾" x 24¾") was available for this model, to provide wider stereo separation.  Permeability tuning is used.  The speakers are Philips type AD3800AM high impedance 800Ω types.

Cabinet finishes in Walnut, Maple & Rosewood.

Price in first year of sale 131.25 AUS £
Literature/Schematics (1) - - Manufacturers Literature (Philips Radioplayer Service Data, December 1960.)
Literature/Schematics (2) J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page P43.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
