For model 22AC860 /80, Philips Radios - Deutschland:
Philips manual

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1977 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 14,4 Volt
Loudspeaker - This model requires external speaker(s).
Power out 10 W (unknown quality)
from Radiomuseum.org Model: 22AC860 /80 - Philips Radios - Deutschland
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179.4 x 43.8 x 136 mm / 7.1 x 1.7 x 5.4 inch
Notes

Stereo output 2x 5W 4Ω.
The Philips Cassette auto radio model 22AC860 was sold in the following versions: /80, /82, /84, /85 and /89. When upload pictures, please do also one with the plate, including the readable subversion. We will upload the complete documentation to each model and you should search into it looking for your particular model data variations.
