22GC006 /00

22GC006 /00; Philips; Eindhoven (ID = 1093291) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093292) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093293) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093294) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093295) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093296) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093297) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093298) R-Player

22GC006 /00; Philips; Eindhoven (ID = 1093299) R-Player
22GC006 /00; Philips; Eindhoven (ID = 1093290) R-Player
Use red slider bar for more.
22GC006 /00; Philips; Eindhoven (ID = 1093290) R-Player
Philips; Eindhoven: 22GC006 /00 [R-Player] ID = 1093290 933x622
Select picture or schematic to display from thumbnails on the right and click for download.
For model 22GC006 /00, Philips; Eindhoven (tubes international!); Miniwatt:
Picture from manual.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1976 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6: BC548 BC548 BC558 BC338 BD135 BD135 BA317 BZX79 BAX18
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-127; 220-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 22GC006 /00 - Philips; Eindhoven tubes
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 385 x 50 x 315 mm / 15.2 x 2 x 12.4 inch
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
