22AF180 /01E

22AF180 /01E; Philips; Eindhoven (ID = 1067695) R-Player
22AF180 /01E; Philips; Eindhoven (ID = 736085) R-Player 22AF180 /01E; Philips; Eindhoven (ID = 962325) R-Player
22AF180 /01E; Philips; Eindhoven (ID = 736080) R-Player 22AF180 /01E; Philips; Eindhoven (ID = 736081) R-Player
22AF180 /01E; Philips; Eindhoven (ID = 736082) R-Player 22AF180 /01E; Philips; Eindhoven (ID = 736083) R-Player
22AF180 /01E; Philips; Eindhoven (ID = 736084) R-Player 22AF180 /01E; Philips; Eindhoven (ID = 736086) R-Player
22AF180 /01E; Philips; Eindhoven (ID = 736087) R-Player 22AF180 /01E; Philips; Eindhoven (ID = 1012651) R-Player
Use red slider bar for more.
22AF180 /01E; Philips; Eindhoven (ID = 736085) R-Player
Philips; Eindhoven: 22AF180 /01E [R-Player] ID = 736085 923x731
Select picture or schematic to display from thumbnails on the right and click for download.
For model 22AF180 /01E, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1978 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) TDA1059 TBA810 1N4002 1N4002
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 220-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: 22AF180 /01E - Philips; Eindhoven tubes
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 300 x 120 x 290 mm / 11.8 x 4.7 x 11.4 inch
Notes Verstärkerbetrieb mit LIN-IC TBA 810 SP (NV-V+E). Speed-Control mit LIN-IC TDA 1059 B. 2 Dioden im Netzteil(1N4002). Leistungsaufnahme 3,5 Watt
Net weight (2.2 lb = 1 kg) 2.1 kg / 4 lb 10 oz (4.626 lb)
Collectors' prices

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
