For model 22AR473 /00, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1970 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 20: BF494 BF495 BC548 BC549 BC558 BD135 BD136 TBA810
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 220 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (4 W max.)
from Radiomuseum.org Model: 22AR473 /00 - Philips; Eindhoven tubes
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 330 x 205 x 80 mm / 13 x 8.1 x 3.1 inch
Notes

Wave range:
LW: 150 - 260 kHz.
MW: 520 - 1605 kHz.
FM:  89,5 - 104 MHz.
One semiconductor per type listed.



Mentioned in -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
