22GF661 /84R /87R

22GF661 /84R /87R; Philips; Eindhoven (ID = 748059) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 748060) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 748061) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 748062) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 748063) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 748064) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 2030074) R-Player

22GF661 /84R /87R; Philips; Eindhoven (ID = 2030075) R-Player
22GF661 /84R /87R; Philips; Eindhoven (ID = 748058) R-Player
Use red slider bar for more.
22GF661 /84R /87R; Philips; Eindhoven (ID = 748058) R-Player
Philips; Eindhoven: 22GF661 /84R /87R [R-Player] ID = 748058 933x536
Select picture or schematic to display from thumbnails on the right and click for download.
For model 22GF661 /84R /87R, Philips; Eindhoven (tubes international!); Miniwatt:
Service-Doku

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1974 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 18: BC149 BC148 BC158 BC148 BC149 BA217 BC148 BC158 BD234 BD233 BC149 BC148 BC158 BC148 BC149 BA217 BC148 BC158 BD234 BD233 BY127 BY127 BY127 BY127
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out 12 W (unknown quality)
from Radiomuseum.org Model: 22GF661 /84R /87R - Philips; Eindhoven tubes
Material Plastics (no bakelite or catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 472 x 300 x 176 mm / 18.6 x 11.8 x 6.9 inch
Notes Stereo-Record changer-amplifier 22GF661 /84R /87R.
With record changer chassis 22GC061 /83 /87.
Source of data -- Original-techn. papers.

Model page created by a member from D. See "Data change" for further contributors.
