HiFi-Stereo-Electrophon 22GF808

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748564) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748565) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748566) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748567) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748568) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748569) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748570) R-Player

HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748571) R-Player
HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 142356) R-Player HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 142357) R-Player
HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 142360) R-Player HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 142359) R-Player
HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 748071) R-Player HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 848722) R-Player
HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 848724) R-Player
Use red slider bar for more.
HiFi-Stereo-Electrophon 22GF808; Philips; Eindhoven (ID = 142356) R-Player
Philips; Eindhoven: HiFi-Stereo-Electrophon 22GF808 [R-Player] ID = 142356 933x614
Select picture or schematic to display from thumbnails on the right and click for download.
For model HiFi-Stereo-Electrophon 22GF808, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1971–1974 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 20: BC149 BC107 BC147 AC127 AC132 BDY38 BY126 BZY94 OA90 BA114
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 20 W (unknown quality)
from Radiomuseum.org Model: HiFi-Stereo-Electrophon 22GF808 - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 415 x 155 x 280 mm / 16.3 x 6.1 x 11 inch
Notes Geschwindigkeiten: 33/45 UpM; Magnetodynamisches System GP370 oder Magnetsystem Super M400. Stereo-NF-Verstärker mit 2 Endstufen je 10 W (Sinus); zwei Lautsprecherboxen 22EG0417 (240×240×80 mm, 1,9 kg) im Lieferumfang.
Einige Halbleitertypen mehrfach vorhanden.
Die VDRG-Handbücher nennen irrtümlich 16 Transistoren.
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Source of data Handbuch VDRG 1971/1972
Mentioned in Handbuch VDRG 1972/1973 (und 1973)
