• Year
  • 1930–1932
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 218405

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • TRF without regeneration; 3 AF stage(s)
  • Tuned circuits
  • 3 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Direct Current supply (DC) / 110;150; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 5 W (unknown quality)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 2453 - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 500 x 290 x 240 mm / 19.7 x 11.4 x 9.4 inch
  • Notes
  • Circuitry simiral to 2553 and 2586.
  • Net weight (2.2 lb = 1 kg)
  • 22 kg / 48 lb 7.3 oz (48.458 lb)
