• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1939/1940

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 7257

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EK2 EF9 EBC3 EL2

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 6/12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: 268 - Philips Radios - Deutschland

• Notes
• Ch=258,259,269

• Source of data
• Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• Lange+Schenk+FS-Röhrenbestückung
