Gleichrichter 450

Gleichrichter 450; Philips Radios - (ID = 541904) Power-S Gleichrichter 450; Philips Radios - (ID = 663929) Power-S
Gleichrichter 450; Philips Radios - (ID = 663930) Power-S Gleichrichter 450; Philips Radios - (ID = 80098) Power-S
Gleichrichter 450; Philips Radios - (ID = 663928) Power-S Gleichrichter 450; Philips Radios - (ID = 847943) Power-S
Gleichrichter 450; Philips Radios - (ID = 1560732) Power-S Gleichrichter 450; Philips Radios - (ID = 1560733) Power-S
Gleichrichter 450; Philips Radios - (ID = 1785495) Power-S Gleichrichter 450; Philips Radios - (ID = 2043482) Power-S
Use red slider bar for more.
Gleichrichter 450; Philips Radios - (ID = 541904) Power-S
Philips Radios -: Gleichrichter 450 [Power-S] ID = 541904 593x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gleichrichter 450, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1926–1934 Category: Power supply/conditioner or battery or charger
Valves / Tubes 1: 451 452
Wave bands - without
Details Power: Charger for A-Batteries
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Gleichrichter 450 - Philips Radios - Deutschland
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 140 x 145 x 140 mm / 5.5 x 5.7 x 5.5 inch
Notes Zylinderförmiger Gleichrichter zum Laden von 1-3 Akku-Zellen (1,3 A).
Net weight (2.2 lb = 1 kg) 2.7 kg / 5 lb 15.2 oz (5.947 lb)
Price in first year of sale 40.00 RM
Source of data Arlt's grosser Radiokatalog 1930 / Radiokatalog Band 1, Ernst Erb
Mentioned in Katalog Radio-Zentrale Prohaska 1930/31 (dick)
Literature/Schematics (1) Philips-Katalog, 1934
