• Country
• Great Britain (UK)

• Manufacturer / Brand
• Philips Electrical, Lamps, Industrial - Miniwatt; London

• Year
• 1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 79303

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• DK32 DF33 DF33 DAC32 DL33 DL33

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 474B - Philips Electrical, Lamps,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 13 x 12.75 x 6 inch / 330 x 324 x 152 mm

• Notes
• Fitted with economy switch which reduces LT/HT from 0.4A/9.5mA to 0.3A/5.5mA.

• Price in first year of sale
• 23.00 GBP

• Source of data
• Radio! Radio!

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
