- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 26929
From an auction catalogue.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 104 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 572A-2 - Philips; Eindhoven tubes
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 610 x 870 x 450 mm / 24 x 34.3 x 17.7 inch
- Notes
- Lautsprecher Type 4283 mit 10 Ohm
- Net weight (2.2 lb = 1 kg)
- 34 kg / 74 lb 14.2 oz (74.89 lb)
- Price in first year of sale
- 350.00 FL
- Source of data
- Overzicht v.de toe te p PHILIPS
- Mentioned in
- Technisch- Commercieel - Radio Vademecum Staleman
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
