• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1973

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 312337

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Metal case

• from Radiomuseum.org
• Model: 5 x 7 inch Oval Standard Loudspeaker AD5780 /X4 /X8 /X15 /X25 - Philips; Eindhoven tubes

• Dimensions (WHD)
• 132.5 x 182.5 x 57 mm / 5.2 x 7.2 x 2.2 inch

• Notes

• Philips 5 x 7 inch Oval Standard Loudspeaker type AD5780 /X

  Available versions:

  • /X4:         Z= 4 Ω @ 115 Hz
  • /X8:         Z= 8 Ω @ 115 Hz
  • /X15:       Z= 15 Ω @ 115 Hz
  • /X25:       Z= 25 Ω @ 115 Hz

• Net weight (2.2 lb = 1 kg)
• 0.320 kg / 0 lb 11.3 oz (0.705 lb)

• Mentioned in
• -- Original-techn. papers. (Miniwatt Copresa "Altavoces" 1973)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
