Philips 飞利浦;: 9-Band World Receiver AE 3205/00 [Radio] ID = 843450 875x677

Select picture or schematic to display from thumbnails on the right and click for download.

For model 9-Band World Receiver AE 3205/00, Philips 飞利浦; China

Country:

People's Republic of China

Manufacturer / Brand:

Philips 飞利浦; China

Year: 1990 ?

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

Semiconductors present.

schematic requested

Main principle	Superheterodyne (common)
Wave bands	Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage	Batteries / addl. power jack / 3 x 1,5 / 4,5 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out
from Radiomuseum.org	Model: 9-Band World Receiver AE 3205/00 - Philips 飞利浦; China
Material	Plastics (no bakelite or catalin)
Shape	Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD)	175 x 105 x 40 mm / 6.9 x 4.1 x 1.6 inch
Notes	Batterien des Typs " Mignon" ( "AA" ). Anschlußbuchsen für ext. Netzteil ( 4,5 V, Hohlstecker, + außen ) und für Kopfhörer. 6 KW - Bereiche.
Net weight (2.2 lb = 1 kg)	0.380 kg / 0 lb 13.4 oz (0.837 lb)

Model page created by Heinz Westerweller. See "Data change" for further contributors.
