730A

730A; Philips - Schweiz (ID = 5225) Radio

730A; Philips - Schweiz (ID = 8028) Radio

730A; Philips - Schweiz (ID = 8029) Radio

730A; Philips - Schweiz (ID = 8030) Radio

730A; Philips - Schweiz (ID = 8031) Radio

730A; Philips - Schweiz (ID = 8032) Radio

730A; Philips - Schweiz (ID = 8033) Radio

730A; Philips - Schweiz (ID = 8034) Radio

730A; Philips - Schweiz (ID = 8035) Radio

730A; Philips - Schweiz (ID = 8036) Radio
730A; Philips - Schweiz (ID = 1027907) Radio 730A; Philips - Schweiz (ID = 2182) Radio
730A; Philips - Schweiz (ID = 1027909) Radio 730A; Philips - Schweiz (ID = 1027910) Radio
Use red slider bar for more.
730A; Philips - Schweiz (ID = 1027907) Radio
Philips - Schweiz: 730A [Radio] ID = 1027907 933x1252
Select picture or schematic to display from thumbnails on the right and click for download.
For model 730A, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1931–1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: E452T E452T E424 E424 C443 506
Main principle TRF without regeneration; 2 AF stage(s)
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 103; 111; 118; 127; 135; 143; 155; 196; 210; 225; 240; 253 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: 730A - Philips - Schweiz
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 390 x 490 x 240 mm / 15.4 x 19.3 x 9.4 inch
Notes Ch=720A;LS=2055 [3331441B; 725101]
Net weight (2.2 lb = 1 kg) 16.5 kg / 36 lb 5.5 oz (36.344 lb)
Price in first year of sale 595.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Mentioned in Les Radio PHILIPS de collection
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Philips - Schweiz
Here you find 287 models, 210 with images and 213 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
