8 Transistor Home Radio NTR-8HA
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1966 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 356509
- Number of Transistors
- 8
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Dry Batteries / D: 5 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.5 cm = 4.9 inch
- Power out
- 1.1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 8 Transistor Home Radio NTR-8HA - Philips; Eindhoven tubes
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 350 x 140 x 150 mm / 13.8 x 5.5 x 5.9 inch
- Notes
-
Das gleiche Radio existiert auch unter dem Nahmen "VISTA". Auf Grund der verwendeten Transistoren wurde das Gerät vermutlich in Japan hergestellt.
- Author
- Model page created by Beat Sager. See "Data change" for further contributors.
