For model 90AL072/00 /50 /65, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 3 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: 90AL072/00 /50 /65 - Philips; Eindhoven tubes
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 128 x 75 x 40 mm / 5 x 3 x 1.6 inch
Notes Transistoren: 9011 (023H), 2× 1402 (027B), 1402 (023D), 2× 1802 (023L) in Gegentaktendstufe mit Trafos. Ferritantenne 79 mm rund 9 mm, Lautsprecherbeschriftung: 8 Ohm, 0,2 W, Taiwan Great A24 R01G. Schaltplan ist eingeklebt, Ohrhöreranschluß über 3,5 mm Klinke, Trageschlaufe, Batterien: 2× LR6; Geräte-Nr,: 126943.
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Source of data - - Data from my own collection

Model page created by Alfred Przybilla. See "Data change" for further contributors.



All listed radios etc. from Philips; Eindhoven (tubes international!); Miniwatt
